Ice Mass Balance (IMB)
Developed by Canadian company MetOcean, it is a buoy that can make long-term observations of the polar environment.


Product Description Ice Mass Balance (IMB) was developed by METOCEAN in collaboration with the Cold Regions Research and Engineering Laboratory (CRREL) to provide long-term measurements of ice sheet temperature, thickness, air temperature, and air pressure.
 Advantage Characteristics  Technical Parameter  Application Scope
Advantage Characteristics
Innovative and Robust design
Ice thickness can be monitored for a long time Shell monitors temperature chain
Technical Parameter
  • Temperature chain It is divided into three parts, each 1.5m long, composed of 45 temperature sensors, each 10cm apart, accuracy <0.1℃
  • Ice thickness sensor Probe 1:1.5m on ice; Probe two: 4.5m under ice, accuracy: < 10mm
  • Atmospheric temperature Cambell 107 temperature probe
  • Atmospheric pressure Vaisala PTB210 pneumatic probe
  • Other sensors Satellite transmitter, GPS receiver, data logger, battery pack
Application Scope
The polar meteorological
Marine science
