OEM Temperature Sensor (Pluger T Reader)

Home ＞ Products ＞ Marine Instruments ＞ Physical Oceanography ＞ OEM Temperature Sensor (Pluger T Reader) ＞ OEM Temperature Sensor (Pluger T Reader)

OEM Temperature Sensor (Pluger T Reader)

Pluger T Reader is designed for high-precision hydrological ambient temperature measurement instruments equipped with third-party equipment.

Product Description Pluger T Reader has the characteristics of small size, high precision, good stability, low power consumption and fast acquisition rate.It has been verified many times that Pluger-T Reader has long-term data stability, and the sampling frequency can be changed according to user needs.It has high precision, reaching the first-level level of national measurement standards and ocean survey specifications, and can meet various hydrological environmental monitoring requirements.

Working Principle

Advantage Characteristics

Technical Parameter

Application Scope

Classic Cases

Working Principle

Pluger T Reader adopts the built-in method of the circuit board, so that the analog signal can be as close as possible to the sensitive components to prevent signal interference。In addition, the lead wire at the tail is also used as the power supply and digital communication line of the sensor with a shielding layer. The shielding effect of the metal material of the casing further improves the anti-interference ability of the signal. The built-in circuit features do not require the user to provide additional circuit space.

Advantage Characteristics

Keeping the characteristics of ultra-low power consumption, the communication rate can reach 57600bps External leads are power supply and digital communication, strong anti-interference ability, increase lead length Standard watertight connector installation structure, directly interchangeable

The sampling rate can be adjusted up to 16Hz Built-in circuit, no need for users to provide additional circuit space, easy to miniaturize and improve reliability Built-in circuit, analog signal close to sensitive components, metal shielding, improved sampling accuracy Wide power supply range

Technical Parameter

Shell Titanium/Stainless Steel
Maximum withstand voltage 7000m
Hardware interface 4-core shielding cable/PHB2.0 connector/welding hole (optional)
Electrical Interface RS232 / RS485 / TTL
Protocol Command Line / Modbus / User customization
Measuring range -5~35℃
Resolution 0.0001℃
Initial accuracy ±0.002℃
Stability 0.002℃/year
Power 3.3V~30V DC
Sample rate 25s~16Hz
Weight 14g（titanium）/ 25g（stainless steel）
Power consumption(5V ) Low power standby (4.8 uA)
